21.8. Printing inherited classes using operator«
- Refer to the learncpp.com
## 23. I/O
### 23.1. I/O Streams
- It is a part of the STL.
- I/O is implemented with `streams`.
<br>
- **stream** is a sequence of bytes that can be accessed sequentially. It may produce or consume amounts data over time.
- **input stream**: used to hold input data from a data producer.
- **output stream**: used to hold output data for a particular data consumer.
- *e.g.* when writing/input data to an device, the device may not be ready to accept that data, so the data will sit in the stream.
- [C++] <=> streams <=> [os]
<br>
- **I/O in C++**: we can use the STL classes to deal with streams
- **input stream**: `istream` & extraction operation (`>>`) is used to remove values from the stream
- **output stream**: `ostream` & insertio operation (`<<`) is used to put vlaues in the stream.\
- `iostream` can handle both i & o
<br>
- **Standard streams**:
- `cin`: an `istream` object tied to the standard input
- `cout`: an `ostream` object tied to the standard output
- `cerr`: an `ostream` object tied to the standard error - unbuffered output
- `clog`: an `ostream` object tied to the standard error - buffered output
### 23.2. Input with istream
- Use `extraction operator (>>)` to read information from an input stream. It skips **whitespace (blanks, tabs, and newlines)**. Use `get(), getLine()` to not discard the whitespace.
- `manipulator` is an object that is used to modify a stream when applied with the `extraction (>>)` or `insertion (<<)` operators. <iomanip>
### 23.3. Output with ostream
https://www.learncpp.com/cpp-tutorial/output-with-ostream-and-ios/
### 23.4. Stream classes for string <sstream>
- String streams provide a buffer to hold data but are not connected to an I/O channel.
- The primary uses of the string stream:
- Display data later then or proccess i/o data.
- Get data into a string stream
- Get data from a string stream
- Convertion strings/numbers
- Clear a string stream
- e.g:
```cpp
#include <sstream>
#include <string>
int main() {
std::stringstream os{};
// input
os << "0xF";
std::cout << os.str();
os.str("0x1 0x2");
std::cout << os.str();
// output
std::string bytesStr = os.str();
std::cout << bytesStr;
os.str("0x0 0xF 0xE 0x2");
os >> bytesStr;
std::cout <<bytesStr;
// conversions
int byte_low = 0xFFF;
int byte_high = 0x001;
os.clear();
os << byte_low << ' ' << byte_high;
std::cout << os.str();
}
23.5. Validation
https://www.learncpp.com/cpp-tutorial/stream-states-and-input-validation/
23.6. File I/O
-
There are three basics file I/O classes:
ifstream: derived fromistreamofstream: derived fromostreamfstream: derived fromstream
-
important: We have to explicitly setup to use file streams:
-
- Open a file: instantiate an object of file I/O class, with the name of the file as a param
-
- Use the insertion («) or extraction (») to r/w
-
- Close a file: call the close() or let file I/O go out of scope.
-
- To delete a file, simply use the remove() function.
- To delete a file, simply use the remove() function.
-
-
File output:
#include <fstream>
#include <iostream>
#include <string>
static void fileOutput() {
std::ofstream outfile{"grs_bytes.csv"};
if (!outfile || !outfile.is_open()) {
std::cerr << "[E] Cannot create the output file";
return;
}
// Put bytes data to the file
// put string
std::string elfBytes{
R"""(
time_s,
gsr_value 0.0, 45.27761157741693 0.005, 41.69912812397066 0.01,
38.13110177547114 0.015, 35.32162785580394 0.02,
31.75617843363382 0.025, 28.352875321528607 0.03,
25.23210282654006 0.035, 21.769688905641132 0.04,
17.99031153059391 0.045, 15.073732055666543 0.05,
15.13550182371759 0.055, 14.69547985289048 0.06,
14.867397107985468 0.065, 14.982082556093832 0.07,
14.893751010484861 0.075, 14.877034044202343 0.08,
14.820590581790071 0.085, 15.1065350504897 0.09,
15.152287796727098 0.095, 14.764395300078201 0.1,
15.118189654760348 0.105, 15.473255351586635 0.11,
14.913896402347113
\n )"""};
outfile << elfBytes;
elfBytes =
"0x0 0x0"
"0x0 0x0"
"0x0 0x0";
outfile << elfBytes;
elfBytes =
"0xF 0xA \
0xE 0xB \
0x0 0x0";
outfile << elfBytes;
outfile.put('E'); // put char
outfile.close();
}
- File input:
static void fileInput() {
std::ifstream inFile{"grs_bytes.csv"};
if (!inFile.is_open()) {
std::cerr << "Error to open file";
}
std::string inputStr{};
std::cout << "========" << std::endl;
while (
inFile >>
inputStr) { // Note that ifstream returns a 0 if we’ve reached the end of the file (EOF)
std::cout << inputStr;
}
std::cout << "========" << std::endl;
// not skip whitespace
inFile.close();
inFile.open("grs_bytes.csv"); // explicitly call open()
inputStr.clear();
while (std::getline(inFile, inputStr)) {
std::cout << inputStr << std::endl;
}
std::cout << "========" << std::endl;
inFile.close();
}
- File Mode:
app: opens the file in append modeate: seeks to the end of the file before reading/writingbinary: opens the file in binary mode (instead of text mode)in: opens the file in read mode (default for ifstream)out: opens the file in write mode (default for ofstream)trunc: erases the file if it already exists
23.6 Ramdom File I/O
- File pointer: Each file stream class contains a file pointer that is used to keep track of the current read/write position within the file
- Ramdom access with
seekg() & seekp() - IOS seek flags:
beg: the offset is relative to the beginning of the file (default)cur: the offset is relative to the current location of the file pointerend: the offset is relative to the end of the file
In programming, a newline (‘\n’) is actually an abstraction. On Windows, a newline is represented as sequential CR (carriage return) and LF (line feed) characters (thus taking 2 bytes of storage). On Unix, a newline is represented as a LF (line feed) character (thus taking 1 byte of storage).
// assume iofile is an object of type fstream iofile.seekg(iofile.tellg(), std::ios::beg); // seek to current file position
